Domestic water pump Grundfos UP UP 20-15 NL=150 mm [59641500]

• Brand: Grundfos
• Product number: LVI-4615604
• Delivery time: approx. 1-5 business days.
• Shipping €9.90 or
• Free pickup, no hidden costs



The pump is of the rotor sleeve type, meaning that the pump and motor form an integrated unit without a shaft seal. The only seals in the unit are two flat seals. The bearings are lubricated by the pumped liquid.
Grundfos product number: 59641500
Brand: Grundfos
Product number: LVI-4615604
Power: 65W
Speed ​​No.: 1
Maximum lifting height: 15 dm
TF class: 110
Maximum permissible operating pressure: 10 bar
Approvals on nameplate: VDE,GS,CE
Materials:
Pump housing: Stainless steel, DIN W.-Nr. 1.4301, AISI 304
Impeller: Composite, PES/PP
Installation:
Ambient max/80 ºC liquid: 80 ºC
Maximum permissible operating pressure: 10 bar
Pipe connection: G 1 1/4
Pressure range: PN 10
Installation dimension: 150 mm
Liquid:
Liquid temperature range: 2 .. 110 ºC
Electrical information:
Input power at speed 3: 65 W
Supply frequency: 50 Hz
Rated voltage: 1 x 230 V
Current in speed 3: 0.28 A
Capacitor size - run: 2 µF
Protection class (IEC 34-5): 44
Insulation class (IEC 85): F
Motor protection: NO
Thermal protection: Impedance protected
Controls:
Junction box position: 9H
Other:
Net weight: 2.1 kg
Gross weight: 2.3 kg
Shipping volume: 0.004 m3
Technical features
Bluetooth standardNo
Energy efficiency classUnknown
Maximum operating pressure10 bar
Insulation class according to IECF
Pulse counter interface No
Self-primingNo
KIWA approvedNo
Dual pumpNo
Protection class (IP)IP44
Operating temperature0 ... 80 °C
Flange pressure class PN 10
Width 175 mm
Width 243mm
Connection voltage1 x 230 V
Connection typeCylindrical external pipe thread

Product codes
SAPAAJ922
HVAC 4615604
PLC 4615604
EAN/GTIN 5708601058738
Manufacturer's product code 59641500
Basic
Package dimensions (L x W x H)197 x 142 x 148 mm
Package volume4.14 l
Package weight2.176 kg
Unit piece
Package sizes1
Sales package contents–
UNSPSC40151510
BrandGRUNDFOS
SupplierGRUNDFOS PUMPS OY AB
