Motion detector Wiser Pir10A 160 Use Zb Val [2609177]

€118,99 EUR

Brand: Schneider Electric
Product number: 2609177
Delivery time: approx. 1-5 business days.
Shipping cost: €9.90 or
Free pickup, no hidden costs.

Wiser is a smart home system that increases home comfort, security and energy efficiency. The Wiser smart home consists of various devices that can be controlled wirelessly in various ways. The Wiser phone application can be used to make convenient situational controls, schedules or automations based on weather changes, for example. The devices also talk to each other, so home functions can be automated without the user's attention. Wiser can be installed in normal cabling or wirelessly. Full use of Schneider Electric's Wiser system requires a central unit (snro 2622118, CCT501901, Matter certified), the Wiser by SE smartphone application, a user account and an internet connection. Use of the system is free of charge. It can also be used in other smart home systems according to the functions they support, e.g. Homey, Home Assistant. NOTE: Use in these systems requires separate applications and the system manufacturer's separate terms of use apply to their use. The system manufacturer is responsible for system support. The device can be integrated into Nordpool's exchange-traded electricity data via a compatible PowerTag.

Product number

2609177
Supplier product number:

WDE002367
EAN code:

3606481497154
Material class

S2626A

Specifications

Model / Type: motion sensor
Sensor type: passive infrared
Control range: 160 °
Color: white
Width : 71mm
With DALI interface: no
Maximum detection range: 8 m
Maximum detection area width: 8 m
HVAC control: no
Height : 71mm
Depth: 44 mm
Installation method: flush-mounted
Ceiling mounting: no
Horizontal viewing angle: 160 °
Maximum duty cycle: 30 min
Protection class (IP): IP20
Illumination level limit value: 5-1000 lx
Maximum switching power: 200 W
Material quality: thermoplastic
Brightness limit adjustable: yes
Minimum on time: 1 s
Voltage type: AC
Frequency : 50Hz
Alarm function: no
Dimming function with dimmer body: no
Animal detection: no
Remote control: yes
Forced shutdown: yes
Pull delay: 0 s
Chainable: yes
Phase selection switch: no
Material: plastic
Halogen-free: yes
Constant light control: no
Suitable as a wireless transmitter: yes
With marking unit: yes
Substation input: yes
Optimal installation height: 1 m
RAL number (equivalent): 9003
Response value sensitivity adjustment: yes
Teaching function for brightness limit value: no
Temperature: 5-35 °C
Transparent: no
Stairway monitoring: yes
Surface material: glossy
Underrun protection: no
Surface protection: untreated
Release delay: 1800 s
Suitable for C load: yes
Remote control: no
Minimum depth (built-in device housing): 46 mm
Insertion length: 45 mm
Antibacterial treatment: no
Forced power-on: yes
Embedding width: 45 mm
Maximum occupancy area: 86 m²
Impact resistance class: IK02
Embedment depth: 27 mm
Connection method: screw connection
Number of channels: 1
Switching power: 2200 W
Product line: Wiser
Two-way radio frequency: yes
Bus system KNX radio: no
Other bus systems: other
Includes bus interface: yes
Bus system radio frequency: yes
Bus system Powernet: no
Bus system KNX: no
Function selector switch: yes
Self-learning switch-off delay: yes
Bus system LON: no
