Device box Sheet metal wall device box 74 MM [1152372]

AUS74.2 is a front-mounted device box with a telescopic base for 1-3 plasterboard walls (wall thickness 9 - 39 mm). Thanks to the telescopic base, the height of the box is 54 - 70 mm. The diameter of the mounting hole is Ø73-74 mm (normal box drill). On the side of the bottom part of the box (top side) there is one Ø20 mm flexible plastic pipe, one Ø8-13 mm / Ø20 mm flexible plastic pipe. On the side of the bottom part of the box (bottom side) there is one Ø16 mm flexible plastic pipe and two strain reliefs for the installation of MMJ cables (Ø8-13 mm). On the bottom there are two strain reliefs for the installation of MMJ cables (Ø8-13 mm). In addition, two low-current cables.
The boxes can be freely connected to each other using the mounting grooves on each side of the box (c/c 71 mm). Each side also has an opening blank, through which the wires can also be routed from one box to another in box combinations. The box has two screw post blanks on each side for the device mounting screws. When making box combinations, the hole in the bottom can be used to mark the center points of the boxes. The box has two mounting blanks for diagonal screws, which can be used to mount the box, for example, to a log wall or to a wooden wall frame.
The enclosure has an IP3X protection class. Made of halogen-free material (IEC/61249-2-21) and meets the requirements of the glow wire test according to standard IEC/EN60670: 2005 (850 °C).
